Description
Achieve professional-grade imaging precision with our 1/2.3″ 10MP 4.6mm M12 Low Distortion Lens. Expertly engineered for high-resolution machine vision, factory automation (FA), and advanced drone photography, this industrial-grade optical lens offers a full 10-Megapixel resolving power. Delivering a wide 82° diagonal field of view alongside an exceptional ultra-low distortion profile (<0.5%), it guarantees geometrically accurate data capture with virtually no edge warping. Featuring a standard M12x0.5 mount and a robust 3G2P hybrid lens structure, it provides the perfect compact solution for upgrading smart vision systems that demand strict measurement accuracy and reliable stability.
Key Features & Product Highlights
- Ultra-Low <0.5% Distortion: Delivers superior geometric保真度 (fidelity), ensuring perfectly straight lines for high-precision industrial inspection and surveying.
- 10MP High-Definition Clarity: Designed specifically for 1/2.3″ high-density sensors, ensuring crystal-clear imaging and sharp contrast without pixel blending.
- 82° Wide-Angle Coverage: Provides an expansive 82° diagonal field of view to maximize area coverage while maintaining an ultra-compact Φ14mm footprint.
- 3G2P Optical Architecture: Combines 3 premium glass elements and 2 precision plastic elements to effectively eliminate chromatic aberrations and minimize thermal focus drift.
Technical Specifications
| Parameter | Specification |
|---|---|
| Image Format | 1/2.3″ |
| Focal Length | 4.6mm |
| Field of View (F.O.V.) | 82°(D) / 71°(H) / 58°(V) |
| Resolution | 10 Megapixel (10 MP) |
| Optical Distortion | < 0.5% |
| Aperture | F4.5 |
| Mount Type | M12 × 0.5 |
| Iris Type | Fixed |
| M.O.D. (Minimum Object Distance) | 0.2m |
| T.T.L. (Total Track Length) | 22.3mm |
| Dimensions | Φ14 × 18.8mm |
| Lens Component | 3G2P (3 Glass + 2 Plastic Elements) |
This product is certified by RoHS and ISO9001 quality management system, supports third-party testing, and complies with EU and domestic security equipment access standards, ensuring reliable quality and full compliance.
Target Applications & Device Compatibility
Core Application Scenarios
This 10MP low distortion fixed focal lens is tailor-made for specialized environments where spatial accuracy is critical. It serves as an exceptional choice for industrial machine vision systems, automated optical inspection (AOI), and robotic alignment setups, where sub-millimeter measurements require zero fish-eye warping. The combination of its wide 82° view and 1/2.3″ sensor format makes it highly reliable for Drone & UAV aerial mapping, GIS land surveying, and agricultural remote sensing. Furthermore, its optimized fixed F4.5 aperture ensures an extended depth of field, making it ideal for commercial high-speed barcode scanning tunnels, retail facial-recognition kiosks, and smart parking access control terminals (ITS).
Compatible Device List
- Sensors: Perfectly optimized for high-resolution 1/2.3″ and 1/2.5″ CMOS sensors (e.g., Sony IMX series, Onsemi, OmniVision).
- Industrial Cameras: Fits standard GigE/USB3.0 board cameras, Raspberry Pi HQ camera modules, and industrial smart cameras.
- Aerial Hardware: Directly compatible with specialized lightweight drone camera modules and customized action camera setups.
- Customization: Supports bespoke alterations for anti-reflective coatings, bandpass filters, or specialized metal barrel threads to match custom enclosures.
“Designed for Industrial Machine Vision, Factory Automation, and UAV Mapping applications.”
Frequently Asked Questions
Q: Why is a distortion rating of <0.5% significant for this lens?
A: Standard wide-angle lenses suffer from severe “barrel distortion” where straight edges appear curved. A profile under 0.5% means the image is virtually distortion-free, allowing AI vision algorithms and mapping software to measure distances accurately without digital correction.
Q: Can this lens be used on smaller sensor formats like 1/3″?
A: Yes, it is fully backward-compatible with 1/2.5″, 1/2.7″, and 1/3″ sensors. When used on a smaller sensor, the image crop factor will simply reduce the field of view slightly, but you will benefit from outstanding center resolution and zero corner vignetting.
Q: What is the benefit of the 3G2P lens component design?
A: The 3 glass elements (3G) provide exceptional light transmission, high scratch resistance, and robust thermal stability to prevent focus drift in hot factory environments. The 2 plastic elements (2P) utilize precision aspherical molding to sharply cut down weight and cost while correcting chromatic aberration.
Q: Does this lens include a built-in IR-cut filter?
A: This standard version comes with multi-layer visible light AR coatings. If your application involves day/night security switching or requires a specific 650nm IR-cut filter, please specify during your inquiry, as we offer custom filter integration.
Q: What is the Minimum Object Distance (M.O.D.) for this optical lens?
A: The M.O.D. is 0.2 meters (20 cm). This allows the camera to maintain ultra-sharp focus on targets situated relatively close to the lens barrel, making it ideal for desktop inspection setups and industrial conveyor belt tracking.
Q: Is the F4.5 aperture suitable for outdoor applications?
A: Yes, an F4.5 aperture is perfect for outdoor drone flights, bright factory floors, and well-lit production lines. It provides a deeper depth of field (DoF), meaning a larger zone in front of the camera remains perfectly in focus simultaneously.
