Description
This 3.7mm 5MP M12 fixed focal lens is designed for 1/3.2″ image format and perfectly matched with OV5653 CMOS sensor. Featuring 94° wide field of view, F2.0 large aperture and 6G full-glass construction, it delivers sharp 5MP high-resolution images with controllable distortion. Widely compatible with Automotive Lens, CCTV Lens, Machine Vision Lens and industrial imaging devices, it balances wide viewing angle, clear imaging and compact installation, ideal for commercial security, vehicle monitoring and industrial vision scenarios.
Product Core Highlights
- 94° ultra-wide viewing angle covers more monitoring area without blind spots
- F2.0 large aperture boosts light intake for clear imaging in low-light environments
- 5MP high resolution restores subtle details for professional vision recognition
- M12×0.5 standard mount supports quick installation with no bracket modification
- 6G full-glass optical structure ensures stable performance and long service life
Detailed Product Specifications
| Parameter | Specification |
|---|---|
| Image Format | 1/3.2″ |
| Focal Length | 3.7mm |
| Field of View(D/H/V) | 94°(D) / 74°(H) / 55°(V) |
| Distortion | -24% |
| Resolution | 5 MP |
| Aperture | F2.0 |
| Mount | M12X0.5 |
| Iris | Fixed |
| Focus | Manual |
| Zoom | Fixed |
| B.F.L. | 5.48mm |
| M.O.D. | 0.3m |
| Construction | 6G |
This product is certified by RoHS and ISO9001 quality management system, supports third-party testing, and complies with EU and domestic security equipment access standards, ensuring reliable quality and full compliance.
Application Scenarios & Compatible Devices
This 3.7mm M12 wide angle lens is specially developed for small-space embedded imaging scenarios, perfectly suitable for vehicle panoramic monitoring, reversing image capture, indoor and outdoor CCTV security monitoring, industrial machine vision detection, intelligent traffic ITS acquisition and small drone aerial reconnaissance. Its 0.3m short minimum object distance adapts to close-range industrial detection and smart home device imaging, while the -24% low distortion design effectively reduces image stretching, maintaining picture authenticity even in ultra-wide viewing mode. The fixed focus and fixed iris structure avoids frequent debugging, stable enough for long-term 24-hour uninterrupted operation in industrial, automotive and security environments.
Compatible with 1/3.2″ mainstream CMOS sensors represented by OV5653, it fits automotive dash cam modules, home security IP cameras, industrial machine vision cameras, intelligent access control cameras and small IoT monitoring devices. It supports manual focus fine-tuning to meet different depth-of-field demands, and the standard M12 interface is universally compatible with mainstream monitoring lens holders in the market.
Designed for automotive, CCTV and machine vision application.
FAQs
Q1: What sensor does this 3.7mm M12 lens match?
A1: It is perfectly optimized for 1/3.2″ format and compatible with OV5653 CMOS sensor, also fits other mainstream 1/3.2″ industrial and security sensors.
Q2: Is this lens suitable for low-light environment use?
A2: Yes. F2.0 large aperture increases light intake significantly, delivering brighter and clearer images in dim indoor or night monitoring scenes.
Q3: Can this lens be used for industrial machine vision detection?
A3: Absolutely. 5MP high resolution, 6G full-glass structure and 0.3m close shooting distance fully meet industrial defect detection and size recognition requirements.
Q4: What is the mount type of this lens?
A4: Adopts standard M12X0.5 thread mount, plug-and-play, no extra adapter needed for most M12 interface camera modules.
