Description
This 1/3″ 6mm Pinhole Lens features M12X0.5 mount, fixed F2.8 aperture and manual focus structure. With 60° diagonal FOV and 0.3m short MOD, it adopts professional pinhole optical design for concealed installation. Optimized for mainstream 1/3-inch CMOS sensors, it is a perfect pick for CCTV, machine vision, industrial FA and ITS monitoring scenarios, delivering sharp, low-profile imaging for compact hidden camera modules。
Product Core Highlights
- Professional pinhole optical design, ultra-compact for concealed hidden installation
- 60° diagonal wide FOV, balanced coverage without exaggerated edge distortion
- F2.8 fixed aperture, stable light input for consistent round-the-clock imaging
- M12X0.5 universal mount, easy direct assembly with most mini camera modules
- 0.3m short minimum object distance, ideal for close-range visual inspection
Detailed Product Parameters
| Parameter | Specification |
|---|---|
| Image Format | 1/3″ |
| Focal Length | 6mm |
| F.O.V. (Diagonal) | 60°(D) |
| F.O.V. (Horizontal) | 48°(H) |
| F.O.V. (Vertical) | 36°(V) |
| Aperture | F2.8 |
| Mount | M12X0.5 |
| Iris | Fixed |
| Focus | Manual |
| Zoom | Fixed |
| M.O.D. | 0.3m |
This product is certified by RoHS and ISO9001 quality management system, supports third-party testing, and complies with EU and domestic security equipment access standards, ensuring reliable quality and full compliance.
Application Scenarios & Compatible Devices
Core Application Scenarios
This 6mm Pinhole Lens is specially designed for scenarios requiring concealed and hidden shooting, widely used in indoor covert security monitoring, commercial anti-theft hidden cameras, factory automated machine vision detection, intelligent ITS traffic surveillance, and mini IoT smart hidden camera projects. Its pinhole lightweight structure saves installation space and avoids exposed lens design. The moderate 60° viewing angle meets daily monitoring and industrial detection coverage demands, while the 0.3m short MOD ensures clear imaging for close-distance part identification and detail capture, perfectly solving the installation limitation of ordinary exposed lenses.
Compatible Devices List
Compatible with 1/3-inch mainstream CMOS sensors, perfectly adapted to covert CCTV cameras, mini hidden surveillance modules, industrial FA machine vision equipment, intelligent traffic capture devices, DIY embedded IoT camera systems and small visual detection modules with M12 interface. It supports direct replacement and assembly, and can also match customized visual system development demands.
Designed for Pinhole CCTV, Industrial Machine Vision and Concealed Surveillance application.
FAQs
Q1: What makes this a Pinhole Lens?
A1: It adopts professional pinhole optical structure with tiny light inlet, ultra-compact size, specially made for concealed hidden installation and covert surveillance.
Q2: Which sensor size does this pinhole lens fit?
A2: Optimized for 1/3″ image format, fully compatible with mainstream 1/3-inch CMOS sensors in the market.
Q3: Is this pinhole lens varifocal or zoomable?
A3: It is a fixed focal and fixed zoom pinhole lens with 6mm fixed focal length, only manual focus adjustable.
Q4: What is the minimum working distance for this pinhole lens?
A4: The minimum object distance is 0.3 meters, supporting clear close-range monitoring and industrial visual inspection.
Q5: Does this pinhole lens meet international quality standards?
A5: Yes, it is RoHS and ISO9001 certified, complies with EU security access regulations and accepts third-party quality testing.
