Low Distortion Drone Lens – S06012006428F67

Description

Key Product Highlights

• • Certified IP67 Waterproof & Dustproof: Built to withstand harsh outdoor elements, making it impervious to heavy rain, dust, and moisture without requiring bulky external camera housings.
  • 12MP Ultra-HD Resolving Power: Features an advanced 6-layer all-glass optical design (6G) to fully resolve high-density 12 Megapixel sensors, delivering stunning clarity across the entire frame.
  • Geometrically Accurate Low Distortion: Keeps TV distortion below -2.9%, minimizing barrel curvature to ensure precise image alignment for scanning and automated mapping.
  • Integrated IR-Cut Filter (IRCF): Outfitted with a premium built-in IRCF layer that blocks infrared light during the day to prevent color wash, providing vivid, true-to-life colors.

Detailed Specifications

Applications & Compatible Equipment

• • Sensors: Optimally fits large 1/2″ sensors and seamlessly compatible with 1/2.3″, 1/2.5″, and 1/2.8″ CMOS imaging modules.
  • Industrial & Outdoor Cameras: Fits all standard IP67 waterproof M12 board cameras, smart industrial cameras, and rugged GMSL2 automotive modules.
  • Mainstream Sensor Systems: Seamlessly integrates with Sony IMX series sensors (like IMX377/IMX477 setups) used in 4K action cameras and premium surveillance gear.
  • Embedded Development Platforms: Perfect for customized industrial imaging blocks connected to Raspberry Pi HQ camera ports, Nvidia Jetson kits, or specialized PCBA boards.

Frequently Asked Questions

• • Q: What are the benefits of the IP67 waterproof rating on an M12 lens?
    • • A: An IP67 rating means this lens is fully dust-tight and can withstand being submerged in water up to 1 meter deep for 30 minutes. It allows you to deploy your M12 lenses outdoors in heavy rain, marine setups, or dusty factories without worrying about inner lens fogging.

  • Q: What does the “6G+IRCF” optical construction mean?
    • • A: It means the lens features 6 precise Glass elements instead of cheaper plastic ones, providing excellent heat stability and clarity. The IRCF (Infrared Cut Filter) reflects infrared wavelengths, keeping daylight colors perfectly natural and realistic.

  • Q: Why is a TV distortion value of <-2.9% important?
    • • A: It classifies this model as a professional low distortion lens. Straight edges like walls, boxes, and lane markers remain linear rather than curved, which is crucial for precise machine vision measurements and mapping software.

  • Q: Can this lens focus on objects that are very close?
    • • A: Yes. The Minimum Object Distance (M.O.D.) is only 0.2 meters (20cm). This allows the lens to capture crystal-clear macro imagery, making it ideal for close-range assembly line scanning or robotic picking.

  • Q: Will this lens fit a standard 1/2.3″ sensor camera?
    • • A: Yes, it will work beautifully. When mounted to a 1/2.3″ sensor, it will provide a slightly narrower field of view (78° Diagonal / 62° Horizontal) but will yield outstanding edge-to-edge sharpness with virtually zero optical vignetting.

  • Q: Is the iris adjustable on this model?
    • • A: No, it has a fixed aperture of F2.8. This ensures a consistent, predictable depth of field and light throughput, which is standard and highly preferred for automated industrial lenses and high-speed robotic vision.
