Description
Elevate your compact imaging systems with our 1/3.2″ 8MP 5mm M6.5 Miniature Lens. Specially engineered for space-constrained applications requiring ultra-high definition, this miniature camera lens boasts an impressive 8-Megapixel resolution and an ultra-short Total Track Length (T.T.L.) of just 5.6mm. Equipped with a precision 5P (five plastic elements) structure and an integrated IR-cut filter, it delivers exceptionally sharp, color-accurate images with an optical distortion of less than 1%. It is the premier choice for next-generation portable and smart vision devices.
Key Features & Product Highlights
- 8MP Ultra-HD Resolution: Delivers crystal-clear 8-Megapixel performance optimized for 1/3.2″ sensors to capture intricate details.
- Ultra-Compact 5.6mm T.T.L.: Low-profile miniature design allows seamless integration into extremely slim and tight hardware spaces.
- Integrated IR-Cut Filter: Features a built-in IR-cut filter to prevent color shift, ensuring vivid and true-to-life daytime imaging.
- Low Optical Distortion: Maintains distortion below 1% (<-1%) for reliable, geometrically accurate inspection and scanning.
Technical Specifications
| Parameter | Specification |
|---|---|
| Image Format | 1/3.2″ |
| Focal Length | 5mm |
| Field of View (F.O.V.) | 60° @ 5.8 |
| Resolution | 8 Megapixel (8 MP) |
| Optical Distortion | < -1% |
| Aperture | F2.2 |
| Mount Type | M6.5 × 0.25 |
| Iris Type | Fixed |
| M.O.D. (Minimum Object Distance) | 0.3m |
| T.T.L. (Total Track Length) | 5.6mm |
| Lens Component | 5P + IR cut (5 Plastic Elements + Infrared Cut Filter) |
This product is certified by RoHS and ISO9001 quality management system, supports third-party testing, and complies with EU and domestic security equipment access standards, ensuring reliable quality and full compliance.
Target Applications & Device Compatibility
Core Application Scenarios
This 8MP M6.5 miniature lens is optimized for applications where device thickness and weight are critical limiting factors. It serves as an excellent optical module for lightweight commercial drones, UAV aerial photography, and action cameras, where high pixel density is needed without adding bulk. Its low distortion (<1%) and 60° field of view also make it highly effective for face-recognition payment terminals, wearable smart glasses, handheld document scanners, high-end consumer IoT devices, and micro-medical endoscope sub-assemblies operating in sterile, compact environments.
Compatible Device List
- Sensors: Perfectly matched with high-resolution 1/3.2″ and 1/4″ CMOS image sensors (including Sony IMX series and OmniVision OV series).
- Miniature Hardware: Fits ultra-slim IoT camera modules, pocket-sized sports DV boards, and customizable flexible PCB camera units.
- Smart Terminals: Tailored for integrated biometric smart locks, tablet front-facing cameras, and industrial handheld computing devices.
- OEM Customization: Supports modifications for specific AR/VR sensor alignment, tailored IR band coatings, or varying barrel lengths.
“Designed for Ultra-Compact Drone, UAV, and High-Resolution Mobile Vision applications.”
Frequently Asked Questions
Q: What are the benefits of the M6.5 mount and 5.6mm T.T.L.?
A: The M6.5 × 0.25 thread defines its ultra-miniature classification, which is much smaller than standard M12 lenses. Combined with a Total Track Length (T.T.L.) of only 5.6mm, it allows the entire camera module to be exceptionally flat, fitting easily into smartphones, thin tablets, and drone bodies.
Q: What does the 5P+IR cut lens component specify?
A: “5P” means the lens is constructed with 5 precision-engineered plastic elements, which drastically reduce the total weight while keeping high optical resolution. The built-in “IR cut” filter blocks infrared light to eliminate color distortion during daytime shooting.
Q: Can an 8MP lens be used on lower resolution camera sensors?
A: Yes, you can use this 8MP lens on lower resolution sensors (such as 2MP or 5MP) as long as the sensor size matches (1/3.2″ or smaller). Doing so will actually maximize the sensor’s potential and yield cleaner images due to the superior resolving power of the lens.
Q: Does this lens require manual focusing?
A: No, this is a fixed focal lens with a fixed iris. Once it is initially threaded and focused onto your camera sensor board during module assembly, it remains fixed. It offers a sharp depth of field starting from its Minimum Object Distance (M.O.D.) of 0.3 meters to infinity.
Q: Is the F2.2 aperture suitable for low-light environments?
A: An F2.2 aperture is quite bright for a miniature lens of this scale. It allows ample light transmission to the sensor, ensuring bright images and fast shutter speeds in normal indoor lighting or outdoor daylight environments.
