Description
This 1/2.9″ 2.1mm M12 Wide Angle lens features an ultra-wide 161° diagonal field of view and 4MP high resolution, built with premium 2G5P optical structure. Designed for security monitoring, automotive imaging, machine vision and industrial IoT devices, it delivers clear panoramic imaging, stable optical performance and compact size for narrow installation spaces. Perfect for users seeking wide coverage, high-definition output and cost-effective optical lens solutions.
Product Core Highlights
- Ultra-wide 161°(D) viewing angle covers larger monitoring areas without blind spots
- 4 Megapixel resolution delivers sharp, high-definition panoramic imaging
- F2.1 large aperture ensures excellent light intake for low-light environments
- Standard M12X0.5 mount for easy installation and wide device compatibility
- Compact 2G5P optical structure with stable performance and long service life
Detailed Product Specifications
| Parameter | Specification |
|---|---|
| Image Format | 1/2.9″ |
| Focal Length | 2.1mm |
| Field of View | 161°(D) / 141°(H) / 82°(V) |
| Resolution | 4 Megapixel |
| Optical Distortion | <-25% |
| Aperture | F2.1 |
| Mount | M12X0.5 |
| Iris | Fixed |
| T.T.L. | 15.12mm |
| B.F.L. | 3.72mm |
| M.B.F.L. | 3.37mm |
| M.O.D. | 0.3m |
| Lens Structure | 2G5P |
This product is certified by RoHS and ISO9001 quality management system, supports third-party testing, and complies with EU and domestic security equipment access standards, ensuring reliable quality and full compliance.
Application Scenarios & Compatible Devices
This ultra-wide angle M12 lens is specially developed for panoramic monitoring and miniaturized imaging equipment. It perfectly fits automotive surround view, vehicle rear view monitoring, community security cameras, smart doorbell imaging, industrial machine vision detection, intelligent traffic ITS capture and drone panoramic auxiliary shooting scenarios. With a minimum object distance of 0.3m, it performs excellently in short-range panoramic shooting and narrow-space embedded installation, effectively reducing equipment layout difficulty and expanding monitoring coverage without assembling multiple cameras.
It is compatible with mainstream 1/2.9 inch CMOS image sensors, and widely matches smart home IoT cameras, automotive panoramic camera modules, industrial vision inspection equipment, small drone aerial auxiliary modules and ITS road monitoring units. The fixed iris and standard M12 thread design enable direct replacement and plug-and-play installation, saving modification time and adaptation cost for system integrators and equipment manufacturers.
Designed for panoramic security and automotive vision application.
FAQs
Q1: What sensor size does this lens support?
A1: It is optimized for 1/2.9″ image format and compatible with mainstream matching CMOS sensors on the market.
Q2: Is this lens suitable for automotive rear view cameras?
A2: Yes, the 161° ultra-wide angle perfectly meets automotive panoramic and rear view blind spot monitoring needs.
Q3: Does this lens support low-light imaging?
A3: The F2.1 large aperture improves light intake capacity, ensuring clear imaging in weak light conditions.
Q4: What mount type does this lens adopt?
A4: Standard M12X0.5 thread mount, compatible with most M12 interface camera modules.
