CCL12802125MP

Description

This 2.1mm 1/2.8″ 6G M12 wide-angle CCTV lens features an ultra-wide 156° diagonal field of view, adopting a premium 6-group glass lens structure with fixed aperture and manual focus design. Built with standard M12X0.5 mount, it delivers clear imaging, stable light intake and reliable adaptability for surveillance, industrial vision, smart home and vehicle monitoring devices. As a professional M12 wide angle lens, it perfectly fits 1/2.8″ sensor devices and meets high-definition monitoring and panoramic shooting demands in narrow installation spaces.

Key Product Highlights

Field of View/Focal Length Advantages

Boasts 156°(D) ultra-wide FOV, covering panoramic monitoring without blind spots

Performance

6G full-glass lens structure restores true colors and reduces optical distortion effectively

Compatibility

Standard M12X0.5 mount, plug-and-play with no extra bracket modification required

Quality Assurance

Fixed F2.5 aperture ensures stable light intake; 0.1m MOD supports close-range clear imaging

Detailed Product Parameter

This product is RoHS certified, ISO9001 quality control certified, supports third-party testing, and complies with EU/domestic security equipment access standards, alleviating customer quality concerns.

Product Application Scenarios and Compatible Device

Core Application Scenarios

Primarily used in vehicle panoramic monitoring, smart home video doorbells, outdoor panoramic CCTV cameras, industrial machine vision inspection, small UAV peripheral monitoring and community public area panoramic surveillance. Especially suitable for intelligent devices and industrial equipment that require ultra-wide panoramic coverage, limited internal installation space and stable all-day imaging performance. The ultra-wide viewing angle eliminates monitoring blind spots, and the 6G optical structure maintains clear imaging in complex light environments, perfectly matching long-term continuous working scenarios of security and industrial equipment.

Compatible Devices List

Compatible with mainstream 1/2.8″ CMOS image sensors. Adapted to panoramic surveillance cameras, vehicle rear view panoramic modules, smart IoT video doorbells, industrial vision detection equipment, miniature CCTV monitoring modules and small intelligent monitoring terminals. Supports customized focal length and FOV parameter adjustment to meet personalized device adaptation needs for global buyers.

Designed for panoramic security and industrial vision application.

FAQs

Q1: What sensor size does this M12 lens support?

A1: It is optimized for 1/2.8″ image format and perfectly matches mainstream 1/2.8″ CMOS sensors.

Q2: Is this lens a zoom or fixed focal type?

A2: It is a fixed focal, fixed zoom design with 2.1mm fixed focal length and manual focus adjustment.

Q3: What is the mounting interface of this lens?

A3: Standard M12X0.5 thread mount, compatible with most mainstream M12 interface monitoring modules.

Q4: What is the minimum object distance for clear imaging?

A4: The minimum object distance is 0.1m, supporting clear close-range shooting and monitoring.

Q5: Does this lens have quality certification?

A5: It has RoHS and ISO9001 certification, complies with EU security access standards and supports third-party testing.
