Description
This 2.56mm fixed focal M12 lens features an ultra-wide 165° diagonal field of view and 4MP high resolution, perfectly designed for 1/2.8″ and 1/3″ image format sensors. Built with 6-glass optical construction and F2.4 fixed aperture, it delivers clear imaging, excellent light intake and stable distortion control. Ideal for CCTV Lens, Automotive Lens, Fisheye Lens and machine vision applications, this wide-angle M12 lens balances compact size, premium optical performance and wide device compatibility for commercial and industrial imaging needs.
Product Core Highlights
- Ultra-wide 165° DFOV eliminates blind spots for full-scene panoramic monitoring
- 4MP high resolution delivers sharp and detailed imaging for daily and industrial use
- 6G optical structure enhances light transmission and improves image restoration ability
- M12X0.5 standard mount supports quick installation and wide equipment adaptation
- Strict distortion control optimizes frame display for real scene reproduction
Detailed Product Specifications
| Parameter | Specification |
|---|---|
| Image Format | 1/2.8″ |
| Focal Length | 2.56mm |
| F.O.V.(IMX290 1/2.8″) | 165°(D) / 140°(H) / 76°(V) |
| F.O.V.(1/3″ Sensor) | 150°(D) / 113°(H) / 82°(V) |
| Resolution | 4 Megapixel |
| Optical Distortion | < -72% |
| TV Distortion (H) | < -9% |
| Aperture | F2.4 |
| Mount | M12X0.5 |
| Iris | Fixed |
| T.T.L. | 14.5mm |
| B.F.L. | 4.38mm |
| Construction | 6G |
This product is certified by RoHS and ISO9001 quality management system, supports third-party testing, and complies with EU and domestic security equipment access standards, ensuring reliable quality and full compliance.
Application Scenarios & Compatible Devices
This ultra-wide angle Fisheye Lens is widely applied in automotive rear view monitoring, residential community CCTV security, smart doorbell cameras, traffic ITS system capture, small industrial machine vision detection and UAV aerial auxiliary imaging scenarios. Its 165° super wide field of view covers more monitoring areas without adjusting shooting angle, suitable for narrow installation space and all-weather indoor and outdoor working environments. The compact body design avoids structural modification, greatly reducing installation cost and later maintenance difficulty for system integrators and equipment manufacturers.
Compatible Device List:
- Fully compatible with 1/2.8″ and 1/3″ mainstream CMOS sensors such as IMX290
- Adaptable to home smart doorbells, mini CCTV cameras, automotive dash cam modules
- Matches industrial vision cameras, traffic monitoring equipment and small IoT surveillance devices
- Standard M12X0.5 interface fits most mainstream camera module brackets in the market
Designed for security, automotive and machine vision application.
FAQs
Q1: What sensor formats does this M12 lens support?
A1: It perfectly matches 1/2.8″ and 1/3″ image format sensors, compatible with IMX290 and other mainstream CMOS sensors.
Q2: Is this lens suitable for outdoor all-weather use?
A2: Yes, the 6G optical construction and stable structural design adapt to indoor and outdoor complex temperature and humidity environments for long-term continuous operation.
Q3: Does this ultra-wide lens support 4MP imaging output?
A3: Absolutely, it is designed for 4 Megapixel resolution, delivering clear and high-definition picture performance.
Q4: What interface type does this lens adopt?
A4: It uses standard M12X0.5 mount, plug-and-play with easy installation and strong versatility.
