CCLA13023MPF

Description

This 1/3″ 2.3mm M12 wide angle lens features a massive 160° diagonal field of view, fixed focal design and IP67 waterproof rating. Built with 2G2P optical structure plus IR cut filter, it delivers megapixel clear imaging with low distortion, perfectly tailored for automotive, CCTV, industrial and machine vision embedded devices. Compact size with manual focus fits narrow installation space and harsh outdoor working environments.

Product Core Highlights

• Ultra-wide 160° FOV covers panoramic monitoring without blind spots
• Low TV distortion<18% ensures natural and undistorted imaging
• IP67 waterproof & dustproof adapts outdoor and industrial harsh environments
• IR cut 2G2P structure realizes day and night consistent clear vision
• M12 fixed mount with compact size easy for embedded installation

Detailed Product Specifications

This product is certified by RoHS and ISO9001 quality management system, supports third-party testing, and complies with EU and domestic security equipment access standards, ensuring reliable quality and full compliance.

Application Scenarios & Compatible Devices

This megapixel wide angle M12 lens is specially developed for panoramic monitoring and embedded visual collection scenarios. It is widely used in automotive rear view systems, vehicle dash cameras, residential and commercial CCTV surveillance, smart video doorbells, traffic ITS road monitoring, factory machine vision detection, outdoor IoT intelligent monitoring equipment and industrial embedded imaging modules. With IP67 waterproof and dustproof performance, it can stably work in rainy, dusty and high-low temperature outdoor environments, effectively reducing later maintenance cost. The ultra-wide viewing angle eliminates monitoring dead angles, meeting full-scene panoramic shooting demands for small and medium-sized intelligent devices.

It is compatible with 1/3 inch mainstream CMOS image sensors, fits all kinds of M12 interface surveillance modules, smart home IoT cameras, automotive imaging modules, industrial machine vision cameras and traffic monitoring equipment. The fixed focal and compact structure requires no extra bracket modification, enabling quick installation and replacement for mass production.

Designed for automotive, CCTV, industrial and machine vision application.

FAQs

Q1: What sensor size does this lens support?

A1: It perfectly matches 1/3″ inch CMOS sensors for stable megapixel imaging performance.

Q2: Is this lens suitable for outdoor use?

A2: Yes, it adopts IP67 waterproof and dustproof grade, adapting to outdoor rainy, dusty and complex working conditions.

Q3: Does it support day and night infrared imaging?

A3: Equipped with 2G2P+IR cut optical structure, it realizes automatic day and night switching and clear infrared imaging.

Q4: What interface does this lens use?

A4: Standard M12X0.5 thread mount, compatible with most mainstream M12 interface camera modules.
