Beschreibung
This high-performance 8-Megapixel M12 Automotive Lens has an extreme 200° FOV and a high-efficiency F2.0 aperture. It is tailored specifically for automotive applications. It features the industry-standard M12 x 0.5 mount, widely adopted for M12 Lenses in automotive camera modules. It also boasts an IP69K-rated waterproof and dustproof construction.
Engineered as a premium Automotive Lens, it suits the next generation of 360° surround-view systems (AVM), autonomous driving assistance, and vehicle AI perception. It also serves as a reliable option for high-demand CCTV Lens and professional machine vision scenarios. It delivers unparalleled clarity and durability for automotive-grade demanding applications.
Scenario-Based Functional Descriptions
200° Ultra-Panoramic Coverage
This Automotive Fisheye Lens has a diagonal FOV of 200°. When paired with the AR0830 sensor, it offers 5.38° horizontal and 3.02° vertical FOV. It captures a near-full hemisphere in a single frame, outperforming standard 180° fisheye options for vehicles.
As a key Automotive Lens for vehicle surround-view (AVM) systems, it creates a larger overlap area for stitching algorithms. This ensures zero blind spots around the vehicle, higher precision in environmental mapping, and smoother real-time feedback. It benefits both drivers and autonomous driving systems.
For supplementary CCTV Lens applications like fleet monitoring, the 200° coverage eliminates the need for multiple cameras. This reduces installation costs.
8MP Resolution & F2.0 Aperture
Equipped with 8-Megapixel high-definition resolution, this Automotive Fisheye Lens delivers sharp, detailed images. These meet the strict requirements of automotive AI object detection and driver assistance systems.
The F2.0 large aperture allows significantly more light intake than conventional F2.8 automotive lenses. Combined with the integrated IRCF in its 6G+IRCF construction, it produces high-contrast, low-noise images even in low-light automotive environments.
Such environments include underground parking lots, night-time driving, or dimly lit urban roads. This makes it a highly dependable Automotive Lens for night-time driving assistance. It ensures consistent performance for AI-powered pedestrian, vehicle, and obstacle detection.
It also serves as a reliable CCTV Lens for 24/7 fleet security.
IP69K Industrial-Grade Durability
This Automotive Fisheye Lens is built to withstand harsh automotive and outdoor conditions. It features an IP69K waterproof and dustproof rating, superior to standard IP67 automotive lenses.
This rugged design makes it a durable Automotive Lens for external vehicle cameras. It resists high-pressure water jets (like those in car washes), road rain, dust, and extreme temperatures.
It also performs reliably as a CCTV Lens for outdoor delivery robots and smart city surveillance. Its core advantage, however, lies in automotive-grade durability. It ensures long-term stability in the harsh daily working environments of automotive external cameras.
Its metal and glass construction (6G+IRCF) further enhances durability for a long automotive service life.
Ultra-Compact TTL & M12 Mount
This Automotive Fisheye Lens has a Total Track Length (TTL) of only 14mm and a 1.9mm focal length. It is specifically designed for space-constrained automotive camera applications.
It leverages the industry-standard M12 x 0.5 mount, an iconic feature of M12 Lenses widely used in automotive vision. This offers exceptional versatility and seamless integration with a wide range of automotive camera modules.
These modules include thin-walled vehicle housings, compact AVM sensors, and miniaturized automotive AI perception units. As a core Automotive Lens for compact vehicle cameras, its low-profile structure ensures easy embedded integration.
It does not compromise optical performance, making it a top choice for automotive engineers. They seek high-performance M12 Lenses for space-limited vehicle vision projects. It also fits small-form-factor CCTV Lens devices.
Detailed Parameter Table
| IMAGE SIZE | Max Φ5.19, 1/2.9″ |
| FOCAL LENGTH | 1.9mm |
| FOV (AR0830) | 200°(D=6.17) |
| 200°(H=5.38) | |
| 100°(V=3.02) | |
| RESOLUTION | 8 MegaPixel |
| F-θ DISTORTION | <-19% |
| APERTURE | F2.0 |
| MOUNT | M12X0.5 |
| IRIS | Fixed |
| FOCUS | Manual |
| ZOOM | Fixed |
| T.T.L. | 14mm |
| CONSTRUCTION | 6G+IRCF |
| WATERPROOF | IP69K |
FAQs
Q: How does the 200° FOV benefit AVM systems?
A: Its 200° FOV provides extra overlap for stitching algorithms (critical for Automotive Lens AVM systems), reducing image stretching, eliminating vehicle blind spots, and enhancing view accuracy for drivers and autonomous systems.
Q: Is this 8MP Fisheye Lens suitable for AMR AI obstacle detection?
A: Yes. With 8MP resolution and F2.0 aperture, it captures sharp details despite <-19% distortion; dewarping ensures reliable AI obstacle detection, and it also performs excellently as an Automotive Lens for vehicle AI perception.
Q: Why is IP69K better than IP67 for outdoor CCTV/Automotive Lenses?
A: IP69K outperforms IP67 by withstanding high-pressure, high-temperature water jets—critical for Automotive Lens used in external vehicle cameras (e.g., car washes), making it more durable for automotive outdoor use.
Q: How does the M12 mount enhance its versatility?
A: The standard M12 mount (iconic for M12 Lenses) enables seamless integration with most automotive camera sensors/modules, fitting core Automotive Lens applications and reducing adapter needs and integration costs.
