Fisheye Lens – S02212814520

Description

1/2.8″ & 1/3″ 2.2mm 5MP F2.0 M12 Fisheye Lens

Unlock expansive 2K panoramic clarity with our professional 1/2.8″ and 1/3″ 5MP 2.2mm M12 fisheye lens. Meticulously optimized for high-density 5-megapixel (2K Ultra HD) sensors, this lens captures an incredible 167° diagonal perspective on 1/2.8″ sensors and 155° on 1/3″ sensor arrays to ensure absolute scene awareness. Featuring an ultra-compact 15.15mm Total Track Length (T.T.L.) and an advanced 2G5P (2 Glass + 5 Precision Plastic Elements) hybrid optical structure, it delivers razor-sharp resolution and excellent contrast while drastically reducing the lens footprint. It stands as a premier optical component for premium automotive surround-view, drone navigation, and compact AI hardware.

Key Product Highlights

• 5MP Ultra-Sharp Resolution: Precision-calibrated optics perfectly resolve fine details and textures on 5-megapixel sensor matrices, delivering flawless edge-to-edge definition.
• 167° Ultra-Wide Panoramic View: Delivers an immersive panoramic field of view (145°H / 90°V on 1/2.8″) to comprehensively eliminate visual blind spots with a single camera module.
• Ultra-Short 15.15mm Profile: With an incredibly short Total Track Length (T.T.L.) of just 15.15mm, this low-profile lens seamlessly embeds into space-constrained camera housings and ultra-thin smart devices.
• Advanced 2G5P Hybrid Structure: Combines 2 premium glass layers at the front for scratch resistance and thermal stability with 5 precision aspheric plastic elements to correct aberrations at an optimized weight.
• Bright F2.0 Aperture: The fast fixed F2.0 iris maximizes light throughput onto the sensor, ensuring bright, low-noise imagery and clean video streams in low-light or standard commercial indoor lighting.

Technical Specifications

This product is certified by RoHS and ISO9001 quality management system, supports third-party testing, and complies with EU and domestic security equipment access standards, ensuring reliable quality and full compliance.

Applications & Device Compatibility

Core Application Scenarios

This 5MP M12 fisheye lens is purpose-built for premium visual hardware requiring high 2K data density paired with an ultra-wide panoramic overview and an ultra-thin footprint. It serves as an ideal optical component for automotive 360° surround-view monitoring systems (AVM), premium front dashcams, and electronic side mirrors where capturing multiple lanes and managing extreme temperature fluctuations is critical. Thanks to its lightweight hybrid build and ultra-short 15.15mm TTL, it excels within commercial mapping drones, UAV navigation networks, and autonomous AGV robotics for seamless real-time obstacle avoidance. Furthermore, it delivers top-tier performance in commercial panoramic indoor dome cameras, premium smart home video doorbells, and intelligent retail analytics platforms.

Compatible Device List

• Sensors: Optimized for large 1/2.8″ high-resolution CMOS sensor arrays (e.g., Sony IMX335) and fully adaptive to 1/3″ formats (e.g., OmniVision, Onsemi series).
• Automotive Tech: Seamlessly integrates into 4K/2K car DVR systems, commercial truck telematics enclosures, and advanced driver assistance systems (ADAS).
• Drones & Robotics: Fits professional FPV quadcopter camera modules, autonomous mobile robots (AMRs), warehouse sorting AGVs, and industrial drone payloads.
• Surveillance Platforms: Fits enterprise high-definition network camera modules, virtual reality (VR) panoramic rigs, and premium smart home IoT doorbells.

“Designed for panoramic 5MP surveillance and high-resolution compact automotive vision applications.”

Frequently Asked Questions

• Q: Why is the 15.15mm T.T.L. value important for hardware design?A: Total Track Length (T.T.L.) is the physical distance from the front tip of the lens to the image sensor. A short 15.15mm T.T.L. means this lens is incredibly compact and flat, allowing your hardware engineers to design ultra-thin camera bodies, low-profile vehicle mounts, or discreet smart doorbells.
• Q: What are the main benefits of the 2G5P hybrid structure?A: The 2G5P structure uses 2 glass elements at the front to protect the optics and minimize thermal focus shifting (heat drift), while incorporating 5 precision aspheric plastic layers to heavily correct optical aberrations and distortion while keeping the overall lens lightweight for drone payloads.
• Q: How does this lens handle dual 1/2.8″ and 1/3″ sensor formatting?A: This lens is multi-sensor compliant. If you install it on a 1/2.8″ sensor, you get a wider 167° perspective. If you move it to a 1/3″ sensor, it crops the edge naturally to a 155° view, meaning hardware engineers can use one single lens SKU across multiple product lines to save cost.
• Q: Can this lens be utilized for night-vision recording?A: Yes. The bright F2.0 aperture allows rich light transmission. When your camera module is paired with external infrared (IR) LED illuminators, the lens elements smoothly process the light spectrum for crisp, low-noise nighttime imaging.
• Q: How do we calibrate the focus on this fixed focal lens?A: Focus is adjusted manually during your camera module’s assembly phase. The operator screws the lens into the M12 thread block while monitoring a live reference monitor. Once peak sharpness at your target distance is reached, it is permanently locked using a thread-locking compound or optical adhesive.
